Description

The new Mavic E-Speedcity wheels are made to last and endure, on an e-bike or a muscular bike, because we know there is nothing worse than being stopped by a mechanical issue on your way to or from work. For bikes with 700C/28´´ wheels.
Key benefits:
Sturdy and durable:
– 32 solid j-bent spokes, handbuilt in Mavic´s factory in Europe Strong freewheel mecanisme handles motor torque up to 120Nm Smooth durable bearings saves muscular and electric power
Keeping you and your bike safe and sound:
– 700 diameter is compatible with wide comfy tyres (up to 64mm) Black reflective stickers are discreet but glow at night Maximum load weight: 180kg
Environment friendly:
– Rims made of 90% of recycled aluminum Manufactured in Europe with components 100% made in Europe
Specifications:
– Wheel: Rear
– Discbreak: Cl
– Diameter: 700
– Frontaxle: 12×142
– Rearaxle: 12×142
Rims:
– Tire: UST Tubeless and tubetype
– Material: S6000 Aluminum
– Valve hole diameter: 65 mm
– Disc brake specific profile
– Height: 21 mm
– Drilling: traditional
– Joint: sleeved
– UST Tubeless Ready
– ETRTO size 29: 622x25TSS
– Internal width: 25 mm
– Hookless profile
– E-Bike specific rim profile
Spokes:
– Lacing: front and rear crossed 3
– Material: steel
– Nipples: steel, ABS
– Count: 32 front and rear
– Shape: j-bent, round, 20 straight gauge
Versions:
– Disc standard: Center Lock® only
– Freewheel: Shimano/Sram
Intended use:
– Recommended tire sizes: 28 to 64 mm (11 to 25)
– ASTM CATEGORY 2 : road and offroad with jumps less than 15cm
– For a longer longevity of the wheel, Mavic recommends that the total weight supported by the wheels doesn´t exceed 180kg, E-bike included
Hubs:
– Axle material: aluminum
– Front and rear bodies: aluminum
– Instant Drive 360 freewheel technology
– Rear: Quick Release, 12×142 and 12×135 compatible
– Front: Quick release, 12×100 and 15×100 through axle compatible
– QRM Auto bearing preload technology
– Hub available for Center Lock brake rotors only
Compatibility:
– Freewheel: Shimano/Sram, convertible to Campagnolo ED11, N3W and XD-R with optional driver bodies
– Rear axle: 12mm thru axle, convertible to Quick Release with optional adapters and axle replacement
– Front axle: 12mm thru axle, easily convertible to quick release with optional adapters Convertible to 15mm with complete axle replacement
Versions
– Disc standard: Center Lock® only
– Freewheel: Shimano/Sram
Compatible Adapters and freewheel bodies:
– 12 to 9mm front adapter for quick release (V2680301)
– 15mm axle (V2373501)
– 12mm front hub cap (V2680501 – Delivered with the wheel)
– 12×142 rear axle adapters (V2510701 – Delivered with the wheel)
– ID360 XD-R freewheel body (V2580101)
– ID360 Shimano / Sram freewheel body (V3430101 – Delivered on the wheel)
– Non-Boost : 12×135 rear axle adapters (V2510901)
– ID360 Shimano Micro Spline alloy freewheel body (V3990101)
– 12 to 9mm rear adapter for quick release (V2510801 (with axle V2373401)
Key technologies:
Instant Drive 360 freewheel technology:
– The new Instant Drive 360 freewheel system is super light and efficient A large contactless rubber seal provides low friction, while a wide array of end caps makes it super versatile
