Description

SHIMANO – Rear FREEHUB – CENTER LOCK – Disc Brake – 12-x148 mm E-THRU Axle – 8/9/10-speed – 11-speed MTB With CENTER LOCK disc rotor mounting, the E-THRU FH-MT400-B freehub offers stiffer wheel rigidity, smooth rotation, and less drag.
Features:
– 148 x 12 mm rear E-THRU
Benefit:
– Stiffer wheel rigidity
– Quick and easy assembly
Specifications:
– SERIES: SHIMANO ACERA M3000 Series
– Average weight 369 g
– Axle Fixing method 12 mm E-THRU
– Thru Axle (Length x Inner Diameter) 148 x 12 mm
– Bearing_Cone CBN
– Brake Type CENTER LOCK disc brake
– Includes Internal Serration Rotor Lock Ring without
– Includes External Serration Rotor Lock Ring without
– Flange diameter (mm) 52.8/53.8
– Flange distance (mm) 63.4
– Internal grease sleeve ✔
– O.L.D. (mm) 148
– Offset (mm) 6.65
– P.C.D. (mm) 44/45
– Quick engagement X (more than 36 times/360 deg.)
– Seal_Freehub body Contact
– Seal_Hub Labyrinth & Contact
– Speeds 8-10-speed, MTB 11-speed
– Spoke Holes 32H, 36H
