Description

Specifications:
– Average weight: 1,238 g
– Spokes_J-bend: Yes
– Axle_Fixing method: 12 mm E-THRU
– Thru Axle Length x Inner Diameter: 148 x 12 mm
– Axle_Thru Axle Length x Inner Diameter (mm)_148x12: Yes
– Bearing_Cone: CBN
– Brake Type: CENTER LOCK Disc
– Front / Rear: Rear
– O.L.D. (mm): 148
– Reflector_AS: CATEYE RR-550-WUA SW
– Reflector_DIN: CATEYE RR317-WUA SW
– Reflector_JIS/CPSC: CATEYE RR-550-WUW SW
– Rim_Height (mm): 21
– Rim_Requires rim tape: X (24 – 622)
– Rim_Rim joint: Sleeve
– Rim_Width (mm): 29.6
– Seal_Freehub body: Contact
– Seal_Hub: Labyrinth & Contact
– Speeds: MTB 12-speed
– Spokes_Butted: 2.3
– Spokes_Number: 24
– Tire_Type: Clincher
– Additional Micro Spline 12-Speed Wheel Spec.
– Center Lock Disc Brake
Technologies:
Micro Spline:
– MICRO SPLINE delivers lightweight aluminum FREEHUB body to reduce weight and 10 teeth top gear.
Use combination with MICRO SPLINE cassette sprocket and FREEHUB.
Center Lock:
– The CENTER LOCK system makes an easy rotor installation possible with spline mount and a lock ring. The lock ring mounting system reduces the total working hours by shortening the amount of time of both installation and de-installation. In addition, the secure fixing by the spline mount enhances precision and rigidity while improving braking efficiency.
