Description

Features:
– 19C wide-profile rim provides better performance with wider tires
– More than 100 g lighter than previous model (WH-RS170)
– Rigid 12 mm axle for both front and rear
– 140 mm disc brake rotor compatible
Specifications:
– Axle_Fixing method: 12 mm E-THRU
– Thru Axle Length x Inner Diameter: 142 x 12 mm
– Axle_Thru Axle Length x Inner Diameter (mm)_142x12: Yes
– Bearing_Cone: CBN finish
– Bearing_Cup: Polish
– Brake Type: CENTER LOCK disc brake
– Compatible Spoke protector: CP-FH08 (23T-28T 11-speed) , CP-WH41 (23-30T 10-speed), CP-WH12 (32T 11/10-speed)
– Disc mount_140mm Disc rotor compatible: Yes
– Disc mount_Center lock: Yes
– Front / Rear: Rear
– Internal grease sleeve: Yes
– O.L.D. (mm): 142
– Rear speeds: 10*/11
– Reflector_AS: CATEYE RR-550-WUA SW
– Reflector_DIN: CATEYE RR-317-WUA SW
– Reflector_JIS/CPSC: CATEYE RR-550-WUW SW
– Rim_Height (mm): 19
– Rim_Requires rim tape: Yes
– Rim_Rim joint: Sleeved
– Rim_Width (mm): 24.6
– Seal_Freehub body: Contact
– Seal_Hub: Contact
– Spokes_Number: 28
– Tire_Recommended size: 28-622 – 42-622
– Tire_Type: Clincher
Technologies:
CENTER LOCK:
– The CENTER LOCK system makes an easy rotor installation possible with spline mount and a lock ring. The lock ring mounting system reduces the total working hours by shortening the amount of time of both installation and de-installation. In addition, the secure fixing by the spline mount enhances precision and rigidity while improving braking efficiency.
